Intellinet Intellinet 10-Port L2 Fully Managed PoE Switch with 8 Gigabit Ethernet Ports and 2 SFP Uplinks

Name: Intellinet 10-Port L2 Fully Managed PoE Switch with 8 Gigabit Ethernet Ports and 2 SFP Uplinks
Brand: Intellinet
SKU: 562003
Price: 410.9 EUR
Availability: InStock

Intellinet 10-Port L2 Fully Managed PoE Switch with 8 Gigabit Ethernet Ports and 2 SFP Uplinks, Managed, L2 /L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U

Manufacturer reference 562003

EAN13 0766623562003

€410.90

Last units

Intellinet 10-Port L2 Fully Managed PoE Switch with 8 Gigabit Ethernet Ports and 2 SFP Uplinks. Switch type: Managed, Switch layer: L2 /L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Provides up to eight PoE network devices with power and data
Two 1G small form-factor pluggable (SFP) module slots
Self-Healing Network - the Powered Device Monitor feature (PDM), also known as PD Alive Check, restarts any connected PoE device that fails to respond or send out network traffic
Domotz compatible for cloud management
PoE power budget of 242 watts
PoE output up to 90 watts on ports 7 and 8 ; PoE output up to 30 watts on ports 1 through 6
Supports 802.1Q VLAN (tag-based and port-based)
10/100/1000 auto-sensing ports that automatically detect optimal network speeds
Supports IEEE 802.3bt/at/af-compliant PoE devices (wireless access points, VoIP phones, IP cameras and more)
Supports IEEE 802.3bt/at/af detection and short circuit, overload and high-voltage protection
All RJ45 ports with Auto-MDIX and NWay auto-negotiation support
20 Gbps switch fabric / switching capacity
SNMP Management and Remote Monitoring (RMON)
IPv4/v6 dual protocol
Supports link aggregation (trunking)
IGMP Snooping for multicast filtering
Supports bandwidth control per port
Supports port mirroring
Supports two types of QoS: CoS and DSCP
Broadcast storm control with multicast packet rate settings
Supports jumbo frames up to 9216 Bytes
Store and forward switching architecture
Full/half duplex operation
Supports 802.3x flow control for full duplex mode and collision-based backpressure for half duplex mode
Supports 8k MAC address entries with Auto-learning and Auto-aging
Buffer memory of 4.1 Mbits
Grounding point to protect equipment from external electrical surges
PoE surge protection (4 kV) for all RJ45 ports
ESD protection up to 8 kV for air and 4 kV for contact
Configuration via Web browser, Telnet, SSH or RJ45 console port
LEDs for power, link/activity, PoE and system
One high-efficiency fan for quiet, reliable cooling
Includes 19" rackmount brackets
Fully NDAA-compliant
