Name: PLANET GSW-1820HP network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Blue
Brand: PLANET
SKU: 4711605285278
Price: 189.9 EUR
Availability: OutOfStock

PLANET GSW-1820HP, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting, 1U

Manufacturer reference 4711605285278

EAN13 4711605285278

€189.90

Out of stock

PLANET GSW-1820HP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 8000 entries, Switching capacity: 36 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Physical Port
16-port 10/100/1000BASE-T Gigabit RJ45 copper with 802.3at PoE injector function
2 1000BASE-X mini-GBIC/SFP slots
Power over Ethernet
Complies with IEEE 802.3af/at Power over Ethernet end-span PSE
Up to 16 ports of IEEE 802.3af/802.3at devices powered
Supports PoE power up to 30 watts for each PoE port, all power up to 240W PoE budget
Each port supports 52V DC power to PoE powered device
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100m
Switching
Hardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
Flow control for full duplex operation and back pressure for half duplex operation
Integrates address look-up engine, supporting 8K absolute MAC addresses
9K jumbo frame supports all speeds (10/100/1000Mbps)
IEEE 802.1Q VLAN transparency
Hardware DIP switch for Standard, VLAN and Extend mode selection
VLAN mode: Ports 1 to 14 cannot communicate with each other, but can communicate with the uplink ports 15 to 16 and SFP ports 17 to 18
Extend mode: Ports1 to 8 have data rate of 10Mbps. The farthest transmission distance up to 250 meters and all ports can communicate with each other
The DIP switch can isolate ports to prevent broadcast storm and defend DHCP spoofing
Automatic address learning and address aging
Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)
Hardware
19-inch desktop size, 1U height
LED indicators for PoE ready and PoE activity
Ethernet Link Energy-saving technology
Link down power savings
Intelligent use of power based on cable length
