LogiLink LogiLink HD0049 matrix switcher AV matrix switcher 5 W
LogiLink HD0049, AV matrix switcher, 6 Gbit/s, Black, Metal, 5 W, 0 - 70 °C
HD0049
4052792062472
€129.90
VAT included
Description
LogiLink HD0049. Product type: AV matrix switcher, Bandwidth: 6 Gbit/s. Housing colour: Black, Housing material: Metal. Power consumption (max): 5 W. Width: 210 mm, Depth: 66 mm, Height: 26 mm
- Allow any A/V source to be displayed on multiple displays at the same time
- The Matrix switching functionality gives you full control of the video source displayed on each monitor
- Compliant to HDMI 2.0 with a bandwidth of 6.0 Gbit/s at 600 MHz per channel (18 Gbit/s total) and HDCP 2.2
- Connection In: 4x HDMI-A, DC Power; Connection Out: 2x HDMI-A, 2x Coaxial, 2x SPDIF (Toslink), 2x 3.5 mm stereo
- Supports Ultra HD 4K/60 Hz (YUV 4:4:4) with 36 bit Deep Color (12 bit per channel) and Full 3D
- Power supply unit: DC 5 V/2 A
- Supports DDC, HDR, CEC, ARC and Downscaler function
- Supports dual-way ARC and audio extractor for both output A and output B
- Support uncompressed audio such as LPCM7.1
- Supported audio data: HDMI: DTS-HD Master Audio™, Dolby TrueHD; SPDIF: Coaxial:DTS/Dolby Digital; Coaxial: DTS/Dolby Digital
- Supports audio output over 3.5 mm stereo, Toslink and Coaxial simultaneously or selectable via IR remote control
- Metal chassis
Data sheet
- Colour
- Black
- Garantie
- 2 ans
- Marque
- LogiLink
- Modèle
- HD0049
- Weight
- 1
Specific References
- EAN13
- 4052792062472
